Blueprint for Engines at Edison Central Station – Armington & Sims 18” x 18

Drawing
This document is a blueprint containing technical specifications for engines used at Edison Central Station, specifically an Armington & Sims 18” x 18” engine. The document consists of a data table listing various values related to boiler pressure, steam consumption, and efficiency at different cutoff points. Additional notes at the bottom describe operational considerations, including steam consumption and clearance percentages. The document is signed by W.J. Murtfeldt, Superintendent of Tests.
Blueprint for Engines at Edison Central Station – Armington & Sims 18” x 18 picture number 1

The Edison Central Station was a key part of Thomas Edison’s electrical infrastructure, providing electric power generation during the late 19th century. This blueprint details the performance characteristics of steam engines used in these power stations. The Armington & Sims engine was a high-speed steam engine commonly used in Edison’s electrical plants due to its reliability and efficiency. The document likely represents testing data or performance evaluations related to optimizing energy consumption and efficiency.

Latimer Family Papers (1870-1996 ) [QPL Full Collection]

Header: "Engines for Edison Central Station Armington & Sims' 18” x 18”" Table Columns (Partial): Cutoff Boiler Pressure (Gauge & True) Steam Expansion Number Calculated Steam per H.P. Actual Boiler Steam per H.P. Condensed Steam per H.P. Ratio Actual to Calculated Steam Notes at Bottom: "200 revolutions per min." "Compression not Computed." "Consumption of Steam will be increased by condensation in pipes and by leaks." "Clearance 5%." Signature: "W.J. Murtfeldt, Supt. Tests."
